C7

C7-4

4-Way Curtain Control Module
Function:
4-Way Strong Current Motor Or Dry Contact Motor

Module ID address can be easily and quickly configured with OLED screen RS485 or C-BUS bus communication mode is adopted to connect the module to the intelligent system.

Module supports key manual switch.
Definition of buttons and interfaces：
1). There are four buttons on the module display screen, which aresetting, adding, subtracting and confirming from left to right;
2). There are 8 buttons on the right side of the module. Each button can switch a single group.
Suggested retail price $1917

Multi point control

Bus electric motor scheme


1. The motor needs to be equipped with a control line, and the curtain box is reserved with a zero line.
2. Electric control + light touch start + power cut hand pull + ultra quiet operation + electronic memory limit + stop in case of resistance.
3. Applicable to the control scheme of intelligent motor in the whole housev.

C7

C7-4

4-Way Curtain Control Module

Safe, stable and fast

Low-key appearance, powerful core
Hundreds of parts deployed, ready to call
